VIEW600
The VIEW600 Modular OTDR with capabilities changing depending on the module chosen
Overview
INNO Instrument proudly introduces VIEW600, a truly modular OTDR with 13 applicable modules, supporting last-mile, access network, FTTX/PON, metro networks. VIEW600 boasts qualified CPU, fast response time, capacitive touch screen, user-friendly GUI, and above all, accurate test result. We guarantee that you can seamlessly test your networks with this changeable smart gear.
Fast Shipping
Carrier information
20k products
Payment methods
24/7 Support
Unlimited help desk
2-day Delivery
Track or off orders
Description
General Product Specifications
-
Display Size 7 inches, High Brightness TFT LCD, resolution of 800×480 Distance Units m / km / mile / ft / kft Range Settings 1.3, 2.5, 5, 10, 20, 40, 80, 120, 160, 360km Pulse Widths 3ns, 10ns, 20ns, 50ns, 100ns, 200ns, 500ns, 1μs, 2μs, 10μs, 20μs Linearity 0.03dB Resolution 0.04m ~ 10.24m Sampling Points 256,000 points Output Power 20mW DimensionsSize (HWD) 6.25H x 8.58W x 2.75D inches Weight 3.75pounds (1.70kg with battery)
